Technical Specifications
- Battery Voltage: 12 V / 24 V (Auto Select).
- Rated Charge Current: 10 A.
- Nominal PV Power (12V): 145 W.
- Nominal PV Power (24V): 290 W.
- Max. PV Short Circuit Current: 13 A.
- Automatic load Disconnect: Yes, Maximum 15 A.
- Maximum PV Open circuit Voltage: 75 V.
- Peak efficiency: 98 %.
- Self-consumption: 10 mA.
- Charge Voltage 'Absorption': 14,4 V / 28,8 V (Adjustable).
- Charge Voltage 'Float': 13,8 V / 27,6 V (Adjustable).
- Charge Algorithm: Multi-stage Adaptive.
- Temperature Compensation: -16 mV/°C resp.-32 mV/°C.
- Continuous Load Current: 15 A.
- Low Voltage disconnect: 11,1 V/22,2 V or 11,8 V/23,6 V or Battery Algorithm.
- Low Voltage reconnect: 13,1 V/26,2 V or 14 V/28 V or Battery Algorithm.
- Protection: Battery reverse polarity (Fuse) / Output Short circuit/ Over temperature.
- Operating Temperature: -30 °C to +60 °C (full rated output up to 40 °C).
- Humidity: 95% Non-condensing.
- Data Communication: VE. Direct.
Enclosure
- Colour: Blue.
- Power Terminals: 6 mm² / AWG10.
- Protection Category: IP43.
- Weight: 0.5 kg.
- Dimensions: 100 mm x 113 mm x 40 mm.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
