Production Description:

Ultra-efficient LiFePO4 electrochemistry

• Capable of 5.2kW (1C) sustained power output.
• Fully rechargeable in less than 2 hours.

Inherently resilient against fade

• Built with premium grade cells proven to last 7500+ cycles even at near-limit use.

Wide scope of peripheral integration

• Serial/ CAN-compatible with inverters & relevant modules of industry-leading brands.

• Compatible with all other 48V pure sine wave inverters configurable to match voltage setpoints.

• 10 year product warranty.

General Specification

• Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
• Nominal Voltage: 51.2V
• Ah Rating: 100Ah @C2, 25°C
• Installed capacity @Vnom 5120 Wh
• Cycle life @100% D0D, 1C: 3000 cycles( 5200Wh)
• Cycle life @100% DoD, C2 : 5000 cycle (5200Wh)
• Cycle life @80% DoD, C2, 7500 cycles (4160 Wh) Recommended continuous use
• Installed Capacity @Vnom: 5 120Wh
• Internal Resistance: ≤ 30mΩ @1kHz AC

Voltage

• Operating Voltage Range: 48.0V ~ 55V.
• Bulk Voltage (max.): 55.2V ± 0.3V.
• Float Voltage: 55.5V ± 0.3V.
• Low-Voltage (min.): 46V.

Current

• Charge Current (max.): 60A continuous | ≤ 60A recommended
• Discharge Current (max.): 100A continuous
• Self-discharge Rate Residual capacity: ≤ 3% /month | ≤ 15% /year
• Recover capacity: ≤ 1.5% /month | ≤ 8% /year

Environmental Requirements

• Operating temperature tange "@Charge: 0°C +50°C, @Discharge: —10°C +50°C"
• Recommended operating environment Temp. range: +15 +35°C | Humidity: 45 75%RH
• Storage environment (if stored < 1 month) Temp. range: -20 - +35°C | Humidity: 45 75%RH
• Storage environment (if stored > 3 months) Temp. range: +10 - +45°C I Humidity: 5 75%RH

Physical Attributes

• Dimensions (excl. front panel & components*) 442mm x 520mm x 178mm (L x W x H)
• Net weight (unboxed) 55.0kg
• Serial communication compatibility CAN and RS485
