General characteristics
- Cell Orientation: 72(4*18)
- Jungle Box: IP65 1 bypass-diodes
- Output Cable: 1280mm
- Glass 3.2mm Solar Glass
- Frame Anodized Aluminium
- Weight: 6.5kg
- Dimensions(mm):1025* 78*25
Electrical Characteristics
- Module Type: 150WP
- Testing Condition: STC
- Maximum Power: 150
- Open Circuit Voltage(V) 24.50
- Short Circuit Current(A): 7.74
- Voltage at Maximum Power(V): 20.30
- Current Maximum Power (A):7.39
- Module efficiency: 18. 85%
Operating Parameters:
- Operation Temp: Minus 40C to 85C
- Power Output Tolerance: 0-+Wp
- Maximum System Voltage: 1000V DC
- Maximum Series Fuse Rating: 10A
- Nominal Operating Cell Temperature: 48C + 2C
Temperature Ratings STC:
- Temperature Coefficient of is: (+)0,04%/K
- Temperature Coefficient of Voc: (-)0,30%/K
- Temperature Coefficient Pmax: (-)0,40%/K
Please note that panel dimensions and specifications are subject to change. Please double check with us that they are correct at time of purchase.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
