Features of LiFePO4 Battery

• Longer cycle life: A LiFePO4 12V Lithium Battery offers more than 2000 cycles which is approx. five times more than a lead-acid battery, helping to minimize replacement cost and reduce total cost of ownership.
• Lighter Weight: About 40% of the weight of a comparable lead acid battery. A "drop in" replacement for lead acid batteries.
• Higher Power: Delivers twice the power of lead acid batteries, even high discharge rate, while maintaining high energy capacity.
• Wider Temperature Range: -20°C~60°C.
• Super Safety: Lithium Iron Phosphate Chemistry eliminates the risk of explosion or combustion due to high impact, over charging or short circuit situation.
• Increased Flexibility: Modular design enables deployment of up to four batteries in series and up to eight batteries in parallel.
• Warranty - 5 years

Technical Specifications

• Nominal Voltage: 12 V.
• Nominal Capacity: 100 Ah.
• Energy: 1280 Wh.
• Internal Resistance: 20 mΩ.
• Cycle Life: >2000 cycles @ 0.2°C 100% DOD.
• Months Self Discharge: <3%.
• Efficiency of Charge: 100% @ 0.5°C.
• Efficiency of Discharge: 96 - 99% @ 1°C.

Mechanical Specifications

• Cell Material: LiFePO4.
• Plastic Case: ABS.
• Dimensions: 342mm x 173mm x 220mm.
• Weight: 13Kg.
• Terminal: M6.
