Features:

• Cell Balancing
• Extend lifetime of battery
• Current >300mA
• Safe and Reliable - The safest LFP battery cell
• Bluetooth built-in - Easy to access battery status
• Battery management system with chip
• Supports series and parallel use
• High compatibility - Support to connect with lead-acid battery

Electrical:

• Nominal Voltage/V: 12.8
• Nominal Capacity/Ah: 100
• Rated Energy/Wh: 1280
• BMS Function: Overcharge, over-discharge, overcurrent and temperature protection
• Recommended Charge Voltage/V: 14.4 - 14.6
• Discharge Cut-off Voltage/V: 10.8
• Standard Charge Current/A: 50
• Max. Charge Current/A: 100
• Continuous Discharge Current/A: 100
• Peak Discharge Current/A@5S: 300
• Voltage Configurations: 12, 24, 36 or 48V
• Increase capacity in series or increasing voltage parallel
• Maximum time between changes: 3 months
• Monitoring: Bluetooth
• Warranty: 3 years

Mechanical:

• Dimensions: 307*169*213
• Weight: Approx. 11.5
• Terminal: M8
• Casing material: ABS

Environment:

• Working Temperature Range/°C: Charge: 0~55 Discharge: -20~60

• Humidity Range/RH: <95%
• Storage temperature/°C: 15~35
• IP protection level: IP65
